SMA Connector – Female – Right Angle
₹21.20 (Incl. of GST 18%)
GST Credit of ₹3.23available.
Know More
- SMA Female Connector
- Right Angle RF Connector
- Compatible with most industry standard antennas
- Can be used where antenna mounting needs to be put out from body of device
- High Quality
- 50 Ohms Impedance
Description
This is SMA Connector of female type with Right Angle Mounting of Antenna. It is also know as RP SMA Connector. It is an industry standard for connection of antenna to any device. This is a PCB Mount Connector with the antenna mount facing the right angle side. This connector enables the antenna insertion from an enclosure, by putting the entry of antenna a little away from the PCB.
Specification
Additional information
| Weight | 3.5 g |
|---|
by Munish (verified owner)
Hi,
It would be very helpful if you could provide its dimensions or yet better, its recommended PCB footprint. Datasheet would be ideal, or any reference to a similar part no. which we can refer.
