CCS811 Digital Gas Sensor

The CCS811 Digital Gas Sensor is an ultra-low power digital gas sensor solution which integrates a metal oxide (MOX) gas sensor to detect a wide range of Volatile Organic Compounds (VOCs) for indoor air quality monitoring with a microcontroller unit (MCU), which includes an Analog-to-Digital converter (ADC), and an I²C interface.

CCS811 Digital Gas Sensor is based on ams unique micro-hotplate technology which enables a highly reliable solution for gas sensors, very fast cycle times and a significant reduction in average power consumption.

Features

• Integrated MCU
• Standard I2C interface
• Optimized low power modes
• Provides eCO2 level or TVOC indication with no host intervention

CCS811 Digital Gas Sensor Modes of Operation

• Mode 0: Idle, low current mode
• Mode 1: Constant power mode, IAQ measurement every second
• Mode 2: Pulse heating mode IAQ measurement every 10 seconds
• Mode 3: Low power pulse heating mode IAQ measurement every 60 seconds
• Mode 4: Constant power mode, sensor measurement every 250ms

In Modes 1, 2, 3, the equivalent CO2 concentration (ppm) and TVOC concentration (ppb) are calculated for every sample.

• Mode 1 reacts fastest to gas presence, but has a higher operating current
• Mode 3 reacts more slowly to gas presence but has the lowest average operating current.

Specifications

• Input Voltage: 1.8V to 3.3V
• Supply Current: 26mA (During Measuring at 1,8V)

For more details, please visit the Downloads Section.
